Usages: An ideal machine to print different materials such as plastic films, aluminum foil, tissue paper,
self adhesive stickers, Vinyl, pvc and carton weight boards etc.
Features:
1, Adopts the anilox roller to spread ink.
2, Unwinding and rewinding are controlled by magnetic power brake, clutch, (or by automatic tension
controller of Mitsubishi).
3, Each printing unit adopts 360 degree for color registration.
4. Each printing unit has one IR drier.
5. The rubber roller can break away automatically while stopping and running at a low speed in order to
avoid ink dried.
6. The main motor is equipped with import stepless regulation of frequency conversion.
7. Unwinding, web guiding, corona treatment，printing, IR drying and rewinding can be finished in one
process.
8, An ideal machine to print many kinds of self-adhesive label or stickers.
Parameters:
|
Model
|
UTR320-6
|
UTR480-6
|
|
Printing speed
|
80m/min
|
80m/min
|
|
Printable color
|
6(color)
|
6(color)
|
|
Max web width
|
320mm
|
480mm
|
|
Max printing width
|
310mm
|
460mm
|
|
Max unwinding diameter
|
600mm
|
600mm
|
|
Max rewinding diameter
|
550mm
|
550mm
|
|
Printing circumference
|
175-320mm
|
175-580mm
|
|
Registration
|
±0.10mm
|
±0.10mm
|
|
Dimension
|
2100x1100x2900mm
|
2100x1300x2900mm
|
|
Weight
|
2600kg
|
3400kg
|
|
Power Supply
|
3Phases, 380V/220V, 50HZ
|
3Phases, 380V/220V, 50HZ
|
