Features:
1. It adopts environment-friendly water-based glue and BOPP film or PET film to laminate paper products.
2. Manual paper feed for both paper lamination and window lamination
3. Reliable frequency converter is equipped for infinitely variable speed, and the operator can change the
machine’s speed easily and guarantee the machine’s running stable.
4. Paper regulating plate can be moved left and right for manual paper feeding adjustment.
5. Glue supplying system supplies and recycles the glue automatically.
6. Dip coating saves glue and homogenizes coating much better.
7. Film trimmer cuts film width to make it meet paper size. The cut film is left on the film release spindle
8. Film perforating wheel perforates film edge to let the laminated paper be separated quite easily.
9. Automatic paper winder rolls up laminated paper. Rewinding speed is adjustable upon applications.
10. The rewinded laminated paper roll can be connected to the cutting machine for quick automatic cut, or
cut manually.
Parameters:
Model
|
SRFM1000
|
SRFM1200
|
Max Paper Size
|
1000*950mm
|
1100*1150mm
|
Paper Thickness
|
105-500GSM
|
105-500GSM
|
Maxi Speed
|
50m/min
|
50m/min
|
Voltage/Frequeney
|
380V/50HZ
|
380V/50HZ
|
Total Power
|
3kw
|
3kw
|
Total Weight
|
800kg
|
850kg
|
Overall Dimensions
|
2400*1500*1500mm
|
2400*1700*1500mm
|
