Products > Printing Machinery > Screen Printing Machines & Accessories > UTFB6080A Clam Shell Screen Printing Machine

Product name : UTFB6080A Clam Shell Screen Printing Machine

Item : 20135904631

Enlarge Image

Back

←[Previous Product] [Next Product]→

Details:

Features:

1, High-precision dual guide rack equipped with heavy duty “MEGADYN” belt, frequency converter, perfect print precision and top stability.

2, 4 cylinders motorized to create even pressure with clear mesh

3, Pressure of flood and squeegee blades can be individually adjusted

4, Speed adjustment of printing process and suitable for different sized screen frames

5, Top-quality aluminum print arms

Parameters:

Model	UTFB-8060A	UTFB-9060A	UTFB-12060A	UTFB-12080A
Max. Printing Size	800*600 mm	900*600 mm	1200*600 mm	1200*800 mm
Max screen frame size	1000*850 mm	1100*850 mm	1400*850 mm	1400*1100 mm
Min screen frame size	600*550 mm	700*550 mm	700*550 mm	700*800 mm
Max. printing speed	1200 pcs/h	1200 pcs/h	1100 pcs/h	1000 pcs/h
Height of Instant Off-screen	0-25mm	0-25mm	0-25mm	0-25mm
Air Pressure	0.4-0.6mpa	0.4-0.6mpa	0.4-0.6mpa	0.4-0.6mpa
Weight	550kg	580kg	620kg	680kg
Printing Thickness	0-50mm	0-50mm	0-50mm	0-50mm
Power	3P4N 50/60Hz 380v 2.2kw	3P4N 50/60Hz 380v 2.2kw	3P4N 50/60Hz 380v 3.2kw	3P4N 50/60Hz 380v 3.2kw
Dimension	157010801450 mm	157010801450 mm	157013801450mm	185013801450 mm
Printing Table size	900*800mm	1000*800mm	1300*800mm	1300*1000mm
