Features:
HY747 series rapier loom is mainly used to weave natural fibers (cotton, wool, hemp), artificial fibers (polyester, rayon, fancy yarn and chenille yarn) into light, medium and heavy fabrics.
Equipped with built-in PLC controller and automatic weft hunting device, this loom meets the multiple requirement in textile weaving industry. It has automatic stop device when the weft get broken as well as semi automatic oil supply device. The machine features stable performance, low noise, easy for operation and less maintenance required.
Parameters:
|
Model
|
HY747
|
|
Shedding Device
|
GT22I, GT222-II
|
|
Reed Width(cm)
|
180/200/220/230/250/280/300/330/360/400
|
|
Speed(rpm)
|
140/160/180/200
|
|
Weft selection
|
4-6 colors
|
|
Weft density
|
5-47 pcs/cm
|
|
Diameter of warp beam (mm)
|
600
|
|
Diameter of take-up roller
|
300
|
|
Power(Kw)
|
1.5
|
|
Dimension
|
4000*1830*1800mm (Model HY747/200)
|
